The Waratah Super Battery in New South Wales reached its full 850-megawatt output on 7 September 2026, and on 9 September discharged 701 megawatts to meet its contracted System Integrity Protection Scheme obligation to Transgrid. The milestone ends more than 11 months of reduced capacity after a transformer failure in October 2025 left the facility running at less than half its rated power.
The restoration returns a critical grid-security asset to full service. But the episode exposed a deeper vulnerability: the state’s transmission network now depends on a single battery while the Hunter Transmission Project — the permanent fix — is not expected until 2029.
For 11 months, the grid-security architecture of Australia’s most populous state depended on a single battery running at less than half its rated capacity. The Waratah Super Battery, designed to act as a shock absorber for the state’s transmission network, operated at full capacity until October 2025, when a high-voltage transformer failed, rupturing its tank wall and draining its oil into a containment bund. From that point until September 2026, the facility remained constrained to 350 megawatts.
That failure left the facility at 350 megawatts — enough to meet only an interim security obligation to Transgrid, the network operator. The remaining merchant capacity, intended to earn revenue in Australia’s wholesale electricity market, was unavailable. The episode exposed a structural truth: the state’s grid-security architecture now rests on a single asset while the permanent fix — the Hunter Transmission Project — is not expected until 2029.
On 7 September 2026, the battery reached its full rated output for the first time since the failure. Two days later, it discharged 701 megawatts, aligning with its contracted System Integrity Protection Scheme obligation. The numbers are a milestone. They are also a reminder of how much rides on one piece of equipment.
A battery restored, a grid still waiting
The failure began in October 2025, when High Voltage Transformer 3 suffered what Akaysha Energy described as a catastrophic failure. The winding damage triggered an overpressure event that ruptured the transformer’s tank wall. The unit self-drained into its bunded area. Transformer 2 was taken offline as a precaution, leaving the plant at 350 megawatts.
Akaysha Energy, the battery’s owner, confirmed in February 2026 that a replacement transformer would arrive in the third quarter. It was manufactured domestically by Wilson Transformer Company, avoiding the 12-to-18-month lead times typical of specialised international orders. Transformer 2 returned to service first; by June 2026, the facility had regained 700 megawatts and its full 1,680 megawatt-hours of energy capacity. The final barrier fell on 7 September, when the replacement Transformer 3 was energised.
On 9 September at 10:15 am, the battery discharged 701 megawatts — matching its contracted 700-megawatt SIPS obligation to Transgrid. Giles Parkinson, editor of Renew Economy, characterized the 9 September discharge as a key test of the battery’s ability to deliver on the SIPS contract. The test appeared to validate the facility’s role as a fast-response grid-security asset, though formal acceptance by Transgrid has not been confirmed.
The SIPS mechanism itself is a stopgap. Transgrid monitors 36 transmission lines in real time. When a contingency threatens stability, the battery injects power instantly while paired generators adjust output. This allows existing lines serving the Hunter, Sydney, and Illawarra regions to operate closer to their thermal limits than would otherwise be possible. The sequence below shows how the battery, the network operator, and the generators interact to preserve stability.
The supply chain behind Waratah reflects a broader consolidation. The original battery system came from Powin Energy, a US-based integrator that later filed for Chapter 11 bankruptcy, struggling against Chinese competitors. Hitachi Energy acquired the project’s Spanish power conversion supplier, Eks Energy. Servicing responsibilities now rest with FlexGen, another US firm that bought Powin’s remaining assets. Cross-border balance-sheet decisions now shape the reliability of a grid asset in New South Wales.
A grid waiting for 2029
The System Integrity Protection Scheme exists because New South Wales cannot wait for transmission upgrades. The Hunter Transmission Project, the permanent reinforcement behind the scheme, is not expected until 2029. Until then, the grid relies on assets like Waratah to squeeze more capacity from existing lines. AEMO‘s 2026 Integrated System Plan remains the central planning reference for how transmission and storage are meant to coordinate — but the timeline is slipping.
James Hay, chief executive of EnergyCo NSW, has called the Hunter Transmission Project a major step toward a more affordable, reliable, and secure energy system. Transgrid, for its part, says the Waratah project is being managed through an adjustment mechanism and network-augmentation framework overseen by the Australian Energy Regulator. The regulatory machinery is in place. The physical infrastructure is not.
The battery’s return to full output is a milestone. It is not a solution. The grid-security architecture of Australia’s most populous state still rests on a single asset while the permanent fix remains years away. The next transformer failure — and there will be one, eventually — will ask the same question again.
Beyond the headline
The bigger picture
Waratah is the most visible example of how grid-scale batteries are being deployed to manage transmission constraints while new lines are built. The pattern reflects a broader challenge across Australia’s National Electricity Market as ageing coal plants retire faster than new transmission can be strung. The implication is a grid that can respond to disturbances in milliseconds but remains structurally incomplete — a system that is fast but not yet finished.
The response gap
The response gap is the distance between what can be delivered instantly through battery dispatch and what requires years of permitting, construction, and commissioning. Waratah can inject power in milliseconds; the Hunter Transmission Project will take until 2029. The two operate on entirely different clocks, and the grid’s security in the intervening years depends on the faster one not failing again.
The reach
Transgrid’s ability to dispatch the battery on command gives the network operator direct leverage over system reliability. When a transmission line trips, the battery responds — and that response keeps wholesale markets stable. For Australian balance sheets exposed to power-price volatility, the battery’s performance is not an engineering detail. It is a financial variable.
The battery is back. The risk is not.
With the Waratah Super Battery back at full output but the Hunter Transmission Project still years away, four groups face distinct decisions.
- Australian energy infrastructure investor
Re-evaluate risk models for grid-scale battery projects in the National Electricity Market. The Waratah case shows that a single component failure can curtail revenue for 11 months, but also that insurance and local manufacturing can shorten repair timelines. Review the Australian Energy Market Operator’s 2026 Integrated System Plan for the transmission and storage buildout assumptions now shaping NSW grid security.
- Western supply chain manager for BESS components
Assess sourcing strategies for specialised battery energy storage system components. The Waratah repair relied on an Australian manufacturer to avoid international lead times of up to 18 months. Diversification and regional manufacturing capabilities are no longer optional — they are the difference between a months-long outage and a year-long one.
- Global energy insurance underwriter
Review underwriting policies for grid-scale battery projects. The estimated AU$50–80 million in losses from the Waratah transformer failure, as estimated by NARDAC partner Dr Tom Harries, provides a benchmark for component failure costs, repair timelines, and business interruption exposure. The successful repair also demonstrates that large batteries are insurable and replaceable assets — but the single-point-of-failure risk remains.
- New South Wales industrial energy consumer
Monitor the ongoing performance of the Waratah Super Battery and the progress of the Hunter Transmission Project. The battery’s return to full output stabilises the grid in the near term, but any further outage would expose the same vulnerability. Check the NSW Government’s EnergyCo Hunter Transmission Project page for the latest approval, design, and construction milestones.
Explainer
- System Integrity Protection Scheme
- A grid-security mechanism in New South Wales that allows the network operator to dispatch battery output while paired generators adjust, keeping transmission within secure limits. It was designed as a stopgap to increase capacity on existing lines serving the Hunter, Sydney, and Illawarra regions. The scheme will remain critical until the Hunter Transmission Project is completed, currently targeted for 2029.
- Transgrid
- The transmission network service provider for New South Wales and the Australian Capital Territory. It operates the high-voltage grid and is the counterparty to the Waratah Super Battery’s System Integrity Protection Scheme contract. Transgrid monitors 36 transmission lines in real time and can dispatch the battery instantly when a contingency threatens system stability.
- Hunter Transmission Project
- A state-significant infrastructure project in New South Wales designed to link inland Renewable Energy Zones to coastal demand centres. It is the permanent transmission reinforcement behind the SIPS stopgap. Early works are expected in late 2026, with construction in early 2027 and completion targeted for 2029.
- AEMO
- The Australian Energy Market Operator, responsible for operating the National Electricity Market and the gas markets. Its 2026 Integrated System Plan is the central planning reference for transmission and storage coordination across Australia’s east coast grid. AEMO’s projections shape where and when new battery and transmission assets are built.
- Frequency Control Ancillary Services
- A set of market services that help maintain the stability of the electricity grid by correcting frequency deviations in real time. Grid-scale batteries like Waratah earn revenue by providing these services alongside energy arbitrage. In August 2026, Australia’s battery fleet earned an estimated AU$28.79 million in combined energy and FCAS revenue, with a 54% capture rate.
